How to Install a Generator Interlock Kit: A Step-by-Step Guide

Why Choose a Generator Interlock Kit Over a Transfer Switch?

As a licensed electrician, you know that providing a safe and reliable standby power system is a common request from clients. While a home standby generator, like a Generac 22kw generator, paired with an automatic transfer switch is a premium solution, many homeowners seek a more budget-friendly option for their portable home generators. This is where the generator interlock kit excels.

Compared to a generator manual transfer switch, an interlock is often less invasive and less expensive. It integrates directly with the existing main service panel, using a sliding metal plate or other listed mechanism to ensure only one power source—utility or generator—can feed the panel at a time. This mechanical “interlock” is the core of its function and is the simplest, most effective form of backfeeding prevention when the kit is listed for the particular panel and installed per the manufacturer’s instructions. Backfeeding is extremely dangerous, posing a lethal risk to utility workers and potentially damaging equipment. A properly executed generator interlock kit installation eliminates this hazard when used and installed correctly.

Pre-Installation: Planning for NEC Compliance

Proper planning is 90% of the job. Before you touch a single wire, you must address several critical factors to ensure safety and NEC compliance. This starts with determining the client’s needs by asking, “how big of a generator do i need?” This requires a thorough load calculation, performed in compliance with NEC Article 220, to identify the essential circuits (e.g., refrigerator, furnace, well pump) the client wishes to power. For optional standby systems (NEC Article 702), manual or nonautomatic configurations permit the user to select which loads are connected; for automatic connection the standby source must be capable of supplying the full load automatically connected, or an Energy Management System (EMS) may be used in accordance with the article.

Once you’ve determined the load, you can help the client select the best generator for their needs, whether it’s a powerful conventional unit like a Predator 13000 watt generator, a quiet propane generator for house, or an inverter-based solar generator for home backup. It’s also a good time to discuss the practical differences between a traditional genset vs inverter generator, focusing on power quality and the stable frequency in generator output required for sensitive electronics.

Next, you must source the correct generator interlock. The kit must be specifically designed and listed for the brand and model of the panelboard. For example, a Siemens panel requires a Siemens generator interlock kit listed for that panel. Always use a UL-listed interlock or other listed device appropriate for the panel to guarantee it has been tested to meet national safety standards and to satisfy the AHJ.

Step-by-Step Generator Interlock Kit Installation Guide

This procedure is intended for licensed electricians. Always follow local codes, manufacturer instructions, and safe work practices. Always assume circuits are energized until you have personally verified they are de-energized. As an operational safety sequence, make sure the generator is connected to the inlet and able to run before energizing the back-fed breaker: recommended sequence is: 1) turn OFF branch breakers (and isolate sensitive loads), 2) turn OFF the main breaker (to isolate utility), 3) connect and start the generator and confirm it is running stably, 4) then engage the generator breaker to supply the house circuits. (Manufacturer instructions may vary; follow the interlock and generator documentation.)

1. Safety First: De-energize the Panel. This is the most critical step. Turn off the main circuit breaker, then shut off the upstream service disconnect. Lock out and tag out (LOTO) the disconnect. Use a multimeter to verify that all power is off inside the panel, testing between phases, phase-to-neutral, and phase-to-ground.
2. Remove the Panel Cover. Carefully remove the dead front to access the breakers and panelboard wiring.
3. Install the Generator Breaker. Find an appropriate empty space for the new double-pole generator breaker per the interlock and panel manufacturer’s layout and instructions (locations vary by panel model). The breaker’s ampacity must match the generator’s output and the power inlet box wiring. A listed fastening method (for example, a breaker retainer or other fastening means required by the panel manufacturer and NEC) is required to secure a back-fed plug-in device as required by NEC rules to prevent accidental disconnection.
4. Mount the Interlock Assembly. Following the manufacturer’s guide, attach the interlock plate to the panel cover. It typically mounts directly over the main breaker and the new generator breaker. Test its mechanical function with the panel cover off the panelboard to ensure it physically blocks one breaker from being switched on when the other is engaged.
5. Install the Power Inlet Box. Mount a weatherproof generator box on the home’s exterior in a location convenient for the portable generator connection. This box will contain the appropriate male generator plug, such as a NEMA L14-30P for 30 A systems or a NEMA 14-50P for many 50 A systems. Choose the inlet type to match the generator and the installed breaker and wiring. For up-to-date inlet placement and installation considerations, you may find 2023 NEC rules for outdoor generator inlets helpful.
6. Wire the Inlet Box to the Generator Breaker. Run the appropriate gauge wire from the power inlet box to the newly installed generator breaker in the main panel. The current-carrying conductors sizing (hot legs and neutral if used) should be selected per ampacity tables (NEC Table 310.16) while the equipment grounding conductor is sized per NEC Table 250.122. For example, the hot conductors for a 50 A feeder are commonly 6 AWG copper for ampacity considerations, whereas the equipment grounding conductor for a 50 A overcurrent device is sized by Table 250.122 (commonly 10 AWG copper per that table). Ensure all connections are torqued to manufacturer specifications.
7. Label Everything. The NEC and good practice require clear labeling. Clearly label the generator breaker and inlet, and apply any instructional or caution labels included with the kit to the panel cover, guiding the user on the proper sequence of operation. Also include any arc-flash or service-connection labels if applicable.
8. Re-install Cover and Test the Interlock. Place the panel cover back on. Test the interlock mechanism one last time. You should not be able to turn on the main breaker and generator breaker simultaneously.
9. Schedule the Electrical Inspection. The final step is to have your work approved by the local AHJ (Authority Having Jurisdiction). A successful electrical inspection confirms your installation is safe and code-compliant. For guidance on changes to interconnection and transfer equipment rules, see how the 2023 NEC updates interconnection and transfer equipment requirements.

Connecting and Operating the System

Once the installation passes inspection, you must educate the homeowner. They will connect their generator to the inlet box using a proper, heavy-gauge generator cord that matches the inlet and breaker. The operational sequence recommended for safety is: 1) turn OFF all branch circuit breakers (isolate individual loads), 2) turn OFF the main breaker, 3) connect and start the generator and verify stable output, 4) engage the generator breaker, and 5) gradually restore essential branch circuit breakers. Always follow the interlock kit and generator manufacturer’s operating instructions and local AHJ guidance.

Critical Considerations for Licensed Professionals

A professional installation goes beyond the basics. Keeping abreast of code changes is essential for any electrical professional offering these services, from residential work to installing industrial generators.

• NEC Article 702: This article governs optional standby systems. Your entire installation, from the listed fastening of back-fed devices to the inlet location, must comply with its requirements or the specific exception for temporary portable connections; permanent interconnections should use listed interconnection or transfer equipment or otherwise meet the conditions set by the code and AHJ.
• Interconnection Rules: The code is constantly evolving. Understanding how the 2023 NEC updates interconnection and transfer equipment requirements is vital for compliance on all generator projects.
• Emergency Shut-Off: For certain installations, new rules apply; be sure you know how 2023 NEC generator emergency stop requirements are different from previous code cycles and whether a given installation needs additional accessible emergency disconnects.
• Generator Type: The power source can vary. While most use gas or a propane generator for home, clients may ask about inverter-based or solar-integrated solutions. These have different connection and interconnection requirements; inverter-based generators or hybrid systems may require dedicated transfer equipment or compliance with Article 705 if they can operate in parallel with the utility.
• Manufacturer Specifics: A Generac standby generator typically requires a listed automatic transfer switch and the manufacturer’s recommended wiring and support. An interlock is intended for connection of portable generators and is not a substitute for the manufacturer’s recommended automatic transfer solutions for permanent standby installations.
