Mastering 480V 3-Phase Voltage Drop on Long Feeder Runs

Minimizing 480V 3-phase voltage drop is critical for efficiency and equipment performance in commercial and industrial settings, especially over long feeder runs. Excessive voltage drop leads to wasted energy, poor motor operation, and potential equipment damage. Properly calculating and mitigating this drop requires a solid understanding of the voltage drop formula, correct wire size computation, and the recommendations within the nec code book. Factors such as conductor length, load current, and conductor impedance all play a significant role. The NEC includes a helpful Informational Note that recommends a voltage drop guideline — about 3% for feeders and about 5% for the total of feeders plus branch circuits — as a design target for reasonable efficiency (this is guidance, not a mandatory rule). This guide provides electricians with the formulas and practical steps needed to manage voltage drop effectively in 480V 3-phase systems, ensuring reliable power delivery to critical loads. For a deeper dive into the foundational principles of this power system, see our article on understanding 480V 3-phase power.

What is Voltage Drop in a 480V 3-Phase System?

Voltage drop is the reduction in electrical potential along the path of a current-carrying wire. In any electrical circuit, the conductor itself has a small amount of resistance. As current flows through this resistance, a portion of the voltage is “lost” as heat, a phenomenon known as I²R loss. While this occurs in all circuits, it becomes particularly significant on long feeder runs where the cumulative resistance of the conductor increases with distance.

In a 480V 3-phase voltage drop scenario, the effects can be pronounced. These systems often power heavy machinery, motors, and sensitive electronic equipment far from the source panel. Consequences of excessive voltage drop include:

• Reduced Equipment Performance: Motors may run hotter and less efficiently, leading to a shorter lifespan.
• Dimming Lights: Lighting systems may flicker or operate at a reduced brightness.
• Wasted Energy: The power lost as heat in the conductors (I²R loss) is energy that does no useful work, increasing operational costs.
• Unreliable Operation: Sensitive electronics may malfunction or shut down if the supply voltage falls below their operational threshold.

NEC Code Book Guidance on Feeder Voltage Drop Limits

The National Electrical Code (NEC) addresses voltage drop as a matter of operational efficiency and good design practice rather than a strict enforceable requirement. The Informational Note in Article 215 recommends limiting feeder voltage drop to about 3% at the farthest outlet and keeping the combined feeder-plus-branch-circuit drop near 5% as a practical target. These recommendations help ensure motors and other equipment operate satisfactorily and efficiently.

For a 480V system, a 3% drop is equivalent to 14.4 volts (480 × 0.03 = 14.4V). While these are informational targets (not mandatory code limits), following them is best practice for professional installations. To learn more about these guidelines, review our detailed article on acceptable voltage drop in the NEC code.

The Voltage Drop Formula for 3-Phase Systems

Accurate wire size computation for long feeders depends on using the correct voltage drop formula. There are two primary formulas used for three-phase systems: an approximate formula for quick estimates and a more precise formula that accounts for impedance.

Approximate Voltage Drop Formula

For general calculations where the power factor is high and conductor reactance is not a major concern, a simplified formula can be used.

Vd = (1.732 × K × I × L) / CM

• Vd = Voltage drop (in volts)
• 1.732 = The square root of 3, a constant for three-phase calculations.
• K (or equivalently the conductor resistance R) = the resistance in ohms for a 1,000-circular-mil conductor per 1,000 ft. In practice use the specific resistance (or R) values from NEC Chapter 9 (Table of conductor resistances). As a rule-of-thumb example, R is roughly 12.9 for copper and about 21.2 for aluminum at elevated operating temperatures (e.g., ~75°C), but you should verify the exact R or K value from the NEC Chapter 9 tables for the conductor and temperature you are using.
• I = The load current in amperes
• L = The one-way length of the conductors in feet
• CM = The cross-sectional area of the conductor in circular mils (found in NEC Chapter 9, Table 8)

Precise Voltage Drop Formula (Using Impedance)

In AC systems, especially with motor loads, using only DC resistance underestimates losses because conductor reactance (X) also contributes. Conductor impedance (Z) = R + jX, and the accurate three-phase voltage-drop expression accounts for both resistance and reactance and the load power factor.

Vd = [1.732 × I × L × (R cosθ + X sinθ)] / 1000

Note: The expression uses R and X in ohms per 1,000 ft, so the division by 1000 aligns units when L is in feet.

• I and L are the same as above.
• R = Conductor resistance in ohms per 1,000 feet (use the values from NEC Chapter 9 resistance table).
• X = Conductor reactance in ohms per 1,000 feet (use the values from NEC Chapter 9 reactance table).
• cosθ = The power factor (e.g., 0.85 for many motors).
• sinθ = The reactive factor of the load: sinθ = √(1 – cos²θ).

Using this more precise formula is crucial for accurate calculations on large industrial jobs. You can explore this topic further in our articles on how to calculate voltage drop and our more advanced voltage drop guide.

Step-by-Step Wire Size Computation for Voltage Drop

Calculating the correct wire size to stay within the recommended voltage drop limits is a fundamental task. Here is a step-by-step process using the approximate formula for simplicity.

1. Determine System Parameters: Identify the voltage (480V), phase (3-phase), load current (e.g., a 100 amp wire size problem), and the one-way distance of the feeder in feet.
2. Establish Allowable Voltage Drop: Decide on the maximum allowable voltage drop based on the NEC informational guidance (about 3% for feeders). For a 480V system, Vd = 480V × 0.03 = 14.4V.
3. Calculate Required Circular Mils (CM): Rearrange the voltage drop formula to solve for CM.

   CM = (1.732 × K × I × L) / Vd
4. Example Calculation: For a 100A load located 400 feet away on a 480V system using copper conductors and using a representative resistance value (K ≈ 12.9 for copper at an elevated operating temperature), the CM result is on the order of 62,000 circular mils. (This is an example calculation; always confirm the exact K or R value using the NEC Chapter 9 tables for the conductor and temperature you will use.)
5. Select Conductor Size: Consult NEC Chapter 9, Table 8 to find a conductor with a circular mil area equal to or greater than the calculated value. In the example, 2 AWG copper (66,360 CM) would be a candidate. However, you must then verify ampacity and any ambient-temperature or grouping adjustments.
6. Verify Ampacity and Other Factors: After selecting a wire size for voltage drop, you must also verify its ampacity from the NEC ampacity tables (Article 310) is sufficient for the load and overcurrent protection. Apply any ambient-temperature correction factors and conductor-count adjustment factors required by the NEC before finalizing the conductor selection.

Ready to go beyond the basics? Master industrial calculations with our advanced electrical courses.

Advanced Strategies for Mitigating Voltage Drop

While increasing the wire size is the most direct solution, other strategies can be employed, particularly in complex industrial environments.

• Increasing Wire Size: This is the most common method. A larger conductor has lower resistance per foot, directly reducing the overall voltage drop.
• Using Parallel Conductors: Installing two or more conductors per phase in parallel effectively creates a single, larger conductor with lower overall impedance. This technique requires that all parallel conductors for a phase are the same length, material, and size, consistent with NEC requirements.
• Reducing Conductor Length: Re-evaluating the equipment layout to place panels and subpanels closer to large loads can significantly reduce feeder length and, therefore, voltage drop.
• Load Balancing: In a three-phase system, ensuring that the load is distributed as evenly as possible across all three phases is crucial for maintaining system stability and preventing voltage imbalances.
• Boosting Source Voltage: In some cases, a transformer with multiple taps can be used to slightly increase the source voltage to compensate for the anticipated drop over a very long run. This requires careful design and coordination with protection settings.

Primary Sources

• National Fire Protection Association (NFPA) for the National Electrical Code (NEC)

Frequently Asked Questions (FAQ)

What is the maximum recommended 480V 3-phase voltage drop according to the NEC?

The NEC, in an informational note in Article 215, recommends a maximum of about 3% voltage drop for feeder circuits and about 5% for the total of the feeder and branch circuit combined as a design target. For a 480V system, 3% is 14.4V.

How does the three-phase voltage drop formula differ from a single-phase formula?

The three-phase voltage drop formula incorporates the square root of 3 (approximately 1.732) to account for the phase relationship in three-phase power delivery. A single-phase round-trip calculation commonly uses a factor of 2 to represent the supply-and-return path and the single-phase geometry.

Why is conductor impedance more critical than just resistance for 480V 3-phase voltage drop calculations?

In AC circuits with inductive loads (like motors), the magnetic fields created by the current induce reactance that contributes to the total opposition to current flow. Conductor impedance combines resistance and reactance and provides a more accurate measure of total opposition, making it essential for precise wire size computation, especially over long runs and at higher frequencies or with heavily inductive loads.

Can a voltage drop calculator replace manual wire size computation?

A voltage drop calculator is an excellent tool for quick estimates and verifying manual calculations. However, a professional electrician must understand the underlying voltage drop formula and factors like power factor impact and conductor reactance to handle non-standard situations and ensure compliance with the nec code book. A calculator is a tool, not a replacement for expertise.
