Understanding Impedance in AC Circuits: A Guide for Electricians

For professional electricians, moving beyond DC theory into alternating current requires a new way of thinking about opposition to current flow. In AC systems, this opposition is called impedance. Understanding impedance in AC circuits is critical for everything from proper conductor sizing and calculating voltage drop to ensuring protective devices operate correctly during a fault. Impedance (Z) is the total opposition to current in an AC circuit, composed of both resistance (R) and Reactance (X). Unlike simple DC resistance, impedance accounts for the energy-storing effects of inductors and capacitors, which are common in motors and electronic loads. This total opposition dictates the true AC Voltage Drop on a circuit and is a key factor in safety calculations and achieving system efficiency through measures like Power Factor Correction. Mastering this concept is essential for any journeyman electrician performing installations, diagnostics, or maintenance.

What is Impedance in AC Circuits?

Impedance, represented by the symbol ‘Z’ and measured in ohms (Ω), is the total opposition that a circuit presents to the flow of alternating current. While it sounds similar to resistance, it’s a more comprehensive concept. In DC circuits, we only have resistance (R), which is the friction against the flow of current. In AC circuits, however, two different types of opposition exist: resistance and reactance. Impedance is the vector sum of these two forces.

This is where Ohm’s Law for AC Circuits comes into play. Instead of V = I * R, the formula becomes V = I * Z. This simple change highlights that we must account for the total opposition—not just resistance—when working with alternating current. To learn more about the fundamental differences between current types, see our guides on AC vs. DC current and the principles of electric charge.

The Components of Impedance: Resistance vs. Reactance

To fully grasp impedance, you must understand its two distinct components: resistance and reactance.

Resistance (R)

This is the same resistance you are familiar with from DC circuits. It is caused by the material properties of conductors and components, and it dissipates energy in the form of heat. Resistance is always present and is not dependent on the frequency of the AC signal.

Reactance (X): The AC-Specific Opposition

Reactance is a form of opposition that only exists in AC circuits. It’s caused by components that store energy—inductors and capacitors. Unlike resistance, reactance doesn’t dissipate energy as heat; instead, it stores and releases it, causing the voltage and current to go out of phase with each other. Reactance is highly dependent on the frequency of the AC signal and comes in two forms.

Inductive Reactance (XL)

Inductive Reactance is generated by inductors, which are coils of wire typically found in motors, solenoids, and the windings of an electrical transformer. When AC flows through a coil, it creates a changing magnetic field that induces a counter-voltage, opposing the change in current. The higher the frequency, the greater the opposition. This is why inductive reactance is critical when working with equipment like a VFD (Variable Frequency Drive), which manipulates frequency to control motor speed.

Capacitive Reactance (XC)

Capacitive Reactance is the opposition offered by a capacitor. Capacitors store energy in an electric field. In an AC circuit, as the voltage alternates, the capacitor continuously charges and discharges, which opposes the change in voltage. Unlike inductive reactance, capacitive reactance *decreases* as frequency increases. This property is essential for applications like motor starting and is the key principle behind Power Factor Correction.

Calculating Total Impedance: More Than Just Simple Addition

Because resistance and reactance are 90 degrees out of phase with each other, you cannot simply add them together. Their relationship must be calculated as a vector sum, often visualized using Phasor Diagrams or the impedance triangle. The formula for total impedance in a simple series circuit is:

Z = √(R² + (XL – XC)²)

This shows how the two types of reactance can cancel each other out. If a circuit’s inductive reactance equals its capacitive reactance, they nullify each other, and the circuit’s total impedance becomes purely resistive.

Impedance in a Series vs Parallel Circuit

The rules for combining impedances change depending on the circuit configuration. Understanding the difference between a series vs parallel circuit is fundamental for correct calculations.

• In Series: Impedances add up. Z_total = Z1 + Z2 + …
• In Parallel: The reciprocals of the impedances add up. 1/Z_total = 1/Z1 + 1/Z2 + …

For a deeper dive into circuit configurations, explore our detailed article on series vs. parallel circuits.

Practical Implications of Impedance for the Journeyman Electrician

Understanding impedance isn’t just theoretical; it has direct, real-world consequences in the field. A professional electrician training program emphasizes these practical applications.

AC Voltage Drop and Conductor Sizing

In AC circuits, impedance—not just resistance—is what causes AC Voltage Drop. The voltage drop formula for AC circuits must account for both the resistance (R) and reactance (X) of the conductors. Longer wire runs and conductors carrying current for inductive loads will have a more significant voltage drop than predicted by DC resistance alone. This is why proper Conductor Sizing, using tables from the National Electrical Code (NEC), is crucial to ensure that voltage at the load remains within acceptable limits.

Fault Current Calculation and Circuit Overload

Impedance is a primary factor in Fault Current Calculation. The lower the total impedance of a circuit, the higher the potential short-circuit current. This is critical for selecting breakers and fuses with an adequate Ampere Interrupting Capacity (AIC). Transformer Impedance, for example, is a key value used to determine the maximum available fault current on its secondary. Furthermore, high Ground Fault Loop Impedance can prevent a breaker from tripping quickly enough during a ground fault, creating a fire or shock hazard. This can lead to a dangerous Circuit Overload condition where conductors overheat without the protective device tripping.

Advanced Concepts: Harmonics, Power Factor, and More

Modern electrical systems often involve more complex issues related to impedance.

• Electrical Noise and Harmonics: Non-linear loads like VFDs and LED drivers introduce harmonic currents into the system. The circuit’s impedance at these higher harmonic frequencies can cause voltage distortion, overheating of transformers, and nuisance tripping.
• Power Factor Correction: Large inductive loads (like motors) cause a poor (lagging) power factor, meaning the utility must supply more current than is actually doing work. By adding capacitors in parallel, the Capacitive Reactance counteracts the Inductive Reactance, bringing the power factor closer to unity (1.0), which improves efficiency and reduces utility bills.
• Impedance Matching: In certain applications like communications or audio systems, matching the impedance of the source to the impedance of the load is critical for maximum power transfer and signal integrity.

Mastering these concepts is crucial for any serious journeyman electrician. Build a rock-solid foundation in electrical theory. Explore our fundamental online electrical courses and electrician training programs.

Step-by-Step: Calculating AC Voltage Drop

Here is a simplified process for calculating the voltage drop in a single-phase AC circuit, demonstrating the practical use of impedance values.

1. Gather Circuit Information: Determine the load current (Amps), the one-way circuit length (feet), and the operating voltage.
2. Find Conductor Impedance: Using NEC Chapter 9, Table 9, find the effective impedance for your conductor size and conduit type (e.g., PVC, steel). This value (Zc) combines both resistance and reactance into a single ohms-to-neutral per 1000 ft value.
3. Identify the Load Power Factor: Determine the power factor (PF) of the equipment being supplied. If unknown, a standard estimate (e.g., 0.85 for motors) can be used.
4. Apply the AC Voltage Drop Formula: While several formulas exist, a common approximate formula is: VD = 2 * L * I * Z / 1000, where L is length, I is current, and Z is the impedance from the NEC table. For more precise calculations, formulas incorporating power factor are used: VD ≈ 2 * L * I * [R*cos(θ) + X*sin(θ)], where R and X are resistance/reactance per foot and θ is the power factor angle.
5. Calculate Final Voltage and Percentage: Subtract the voltage drop from the source voltage to find the voltage at the load. Ensure the percentage drop does not exceed NEC recommendations (typically 3% for a branch circuit and 5% total).

Key Takeaways on AC Impedance

• Impedance (Z) is the total opposition to AC current, combining resistance (R) and reactance (X).
• Inductive Reactance (XL) comes from coils (motors, transformers) and increases with frequency.
• Capacitive Reactance (XC) comes from capacitors and decreases with frequency.
• Impedance dictates the true AC Voltage Drop and is essential for correct Conductor Sizing.
• Low impedance leads to high fault currents, a critical factor in Fault Current Calculation and overcurrent protection.
• Managing reactance is key to Power Factor Correction and mitigating Electrical Noise and Harmonics.

Frequently Asked Questions (FAQs)

What is the difference between resistance and impedance in AC circuits?

Resistance is the opposition to current that dissipates energy as heat and exists in both AC and DC circuits. Impedance in AC circuits is the total opposition, which includes both resistance and Reactance (opposition from capacitors and inductors that store and release energy).

How does impedance affect Fault Current Calculation?

Fault current is inversely proportional to impedance (I = V/Z). A lower total circuit impedance—including the Transformer Impedance and conductor impedance—will result in a higher available fault current during a short circuit or ground fault. Accurate Fault Current Calculation is therefore essential for selecting correctly rated protective devices.

Why is Power Factor Correction important for circuits with high inductive reactance?

High Inductive Reactance from motors causes current to lag behind voltage, creating a poor “lagging” power factor. This means more current is drawn from the source than is doing useful work. Power Factor Correction adds capacitors to the circuit, whose Capacitive Reactance counteracts the inductive reactance, bringing the current and voltage more in phase and improving overall system efficiency.

Can I use the standard Ohm’s Law for impedance in AC circuits?

Yes, but you must use the impedance value (Z) instead of just resistance (R). The formula becomes V = I * Z. Because impedance is a complex quantity (having both magnitude and a phase angle), calculations often require vector math or the use of Phasor Diagrams to be completely accurate, especially when combining series and parallel components.
