Understanding Electric Meter Sockets and Bases

Your Expert Guide to Meter Sockets

An electric meter base, also known as a meter socket, is a critical enclosure that houses the utility’s electric meter, serving as the official demarcation point between the utility’s service drop and the customer’s wiring. For electricians, understanding the nuances of these components is non-negotiable for a safe, code-compliant service installation. The selection process involves much more than just picking a box; it requires a deep understanding of meter socket specifications, amperage ratings like the common 200 amp meter base, bypass types, and the crucial distinction between ringless vs ring type designs. Most importantly, every installation hinges on securing utility company approval for the specific equipment used. This guide provides a comprehensive overview of meter sockets, ensuring you have the expert knowledge required for your next service installation.

The Critical Role of the Electric Meter Base in Service Installations

The meter base is the heart of the electrical service entrance. It’s the weatherproof cabinet that holds the watt-hour meter, securely connecting the utility’s power to the customer’s load-side wiring. The utility’s service entrance conductors terminate on the line-side lugs of the socket, and the customer’s load-side conductors connect to the corresponding load-side lugs. This enclosure not only provides a secure mounting point for the meter but also protects these vital connections from environmental damage and unauthorized access, ensuring the integrity and safety of the entire electrical service.

Key Meter Socket Specifications Every Electrician Must Know

Selecting the correct meter socket involves navigating a variety of specifications that are often dictated by the local utility provider and the National Electrical Code (NEC).

Amperage Rating: From 100A to Class 320 Service

The amperage rating of the meter base must match or exceed the service rating. While 100-amp services were once common, the 200 amp meter base is now the standard for most new single-family homes, accommodating modern electrical loads. For larger residences or small commercial applications with higher demands, a Class 320 service (rated for 320A continuous, 400A non-continuous) is often required. The meter base for a Class 320 service is physically larger and uses different self-contained meters than its 100A and 200A counterparts.

Ringless vs Ring Type: Which to Choose?

The debate between ringless vs ring type meter sockets comes down to security, accessibility, and utility preference.

• Ring Type: Features a sealing ring that secures the meter and cover. The ring is locked with a utility tag. This design is older but still used in many areas.
• Ringless Type: Features a hinged cover that closes over the meter, with a latch at the bottom or side for the utility’s lock and seal. This design is generally considered more secure and tamper-resistant, as the meter is not accessible until the entire cover is unlocked and opened by utility personnel.

The choice is almost always dictated by the local utility’s requirements, so always confirm before purchasing.

Short Circuit Current Rating (SCCR)

The short circuit current rating (SCCR) is one of the most critical safety specifications. It indicates the maximum level of short-circuit current that the meter socket can safely withstand. The SCCR of the meter base must be equal to or greater than the available fault current at its location. Failure to do so can result in catastrophic equipment failure. As a professional, you must know how to comply with 2023 NEC service equipment labeling requirements, which includes clearly marking the SCCR.

Understanding Bypass Mechanisms: Lever Bypass vs. Horn Bypass

Bypass mechanisms allow utility workers to safely remove the meter for maintenance or replacement without interrupting power to the customer. This is accomplished by creating an alternate path for the current to “bypass” the meter socket stabs.

The Lever Bypass Meter Socket

A lever bypass meter socket incorporates a handle-operated mechanism that closes a set of internal contacts, shunting the current around the meter jaws. This provides a safe, built-in method for bypassing the meter. These are commonly found in commercial and multifamily residential applications where service continuity is paramount. The lever mechanism is robust and provides a clear visual indication of whether the socket is in bypass mode.

The Horn Bypass Assembly

A horn bypass assembly uses extended contacts (horns) on the line and load side of the meter jaws. Utility personnel can connect temporary jumpers across these horns to bypass the meter before pulling it. While it requires external equipment (jumpers), the horn bypass assembly is a simple, cost-effective design commonly specified by utilities for single-family residential services.

Installation Considerations: From Mounting to Conductor Termination

Step-by-Step: When to Install a Fifth Jaw Kit

For certain services, a standard four-jaw meter socket is insufficient. A fifth jaw kit is required for services that use a combination of phases and a neutral to provide both 120V and 208V, common in network service areas or multifamily dwellings.

1. Verify Service Type: Confirm with the utility if the service is a 240/120V single-phase, 3-wire service (no fifth jaw) or a 208Y/120V network service (fifth jaw required).
2. Identify Position: The fifth jaw is typically installed at the 9 o’clock position in the meter socket. Some sockets have provisions for 3 o’clock or 6 o’clock placement as well.
3. Connect to Neutral: The fifth jaw connects to the neutral bus within the meter base, providing a necessary reference point for the specialized polyphase meter.
4. Secure and Test: Ensure the jaw is securely fastened and makes solid electrical contact with the neutral assembly.

Overhead vs Underground Service Connections

The choice of meter base also depends on whether the installation is for an overhead vs underground service. Sockets designed for overhead service will have a hub opening at the top to accept a conduit mast and weatherhead. Sockets for underground service will not have a top hub and will instead feature concentric knockouts on the bottom or back for underground conduit entry.

Grounding and Bonding Requirements

Properly installing an electric meter base is incomplete without meticulous attention to grounding and bonding requirements as outlined in NEC Article 250. This involves bonding the metal enclosure to the service neutral and connecting it to the grounding electrode system. These connections are fundamental for clearing faults and protecting against shock hazards.

The Meter Main Combo: An Integrated Solution

A meter main combo is a popular all-in-one unit that integrates the meter socket and the main service disconnect into a single enclosure. This solution streamlines installation, saves space, and reduces labor costs. It’s an efficient way to meet NEC rules regarding service disconnects, particularly when determining how many service disconnecting means are allowed per service. Furthermore, many meter main combos are designed to specifically address the 2020 and 2023 NEC updates detailing how outdoor emergency disconnects are required for one- and two-family dwellings.

Ensuring Compliance: Utility Company Approval and UL Listings

No aspect of meter socket installation is more important than compliance. Before a single screw is turned, you must ensure the equipment meets all local and national standards.

• Utility Company Approval: Every utility maintains a list of approved meter socket manufacturers and model numbers. Installing an unapproved electric meter base will result in a failed inspection and refusal to connect service. Always check the utility’s latest standards.
• UL Listed Meter Socket: To comply with the NEC, the equipment must be listed and labeled by a qualified testing laboratory. Always use a UL listed meter socket to ensure it has been tested for safety and performance.
• Enclosure Rating: For outdoor installations, a NEMA 3R enclosure is the minimum requirement. This rating ensures the enclosure is weather-resistant and provides protection against rain, sleet, and snow.
• Physical Dimensions: When clients or apprentices ask “how big is a meter base?” the answer involves more than just the box dimensions. You must account for NEC working space clearances (NEC 110.26) and specific utility-mandated mounting heights.

The complexities of service installations are always evolving. Master every component of a service installation with our comprehensive NEC courses.

Primary Sources

For the most current and authoritative information, always refer to the official publications from the National Fire Protection Association (NFPA), home of the NEC, and your local utility’s service standards manual.

• NFPA 70, National Electrical Code (NEC)

Frequently Asked Questions (FAQ)

What is the most common electric meter base for residential use?

The most common type is a 200 amp meter base. Whether it is a ringless vs ring type will depend entirely on the local utility company’s standards, with ringless designs becoming more prevalent due to their enhanced security.

Do I need a lever bypass meter socket for a home?

Typically, no. For most residential services, utilities specify a socket with a horn bypass assembly. A lever bypass meter socket is an expensive feature generally reserved for commercial applications or multifamily buildings where maintaining continuous power during meter servicing is critical.

Where can I find the approved meter socket specifications for my area?

The only reliable source for meter socket specifications is the electric utility company that will be providing power. Their engineering standards or service requirements guide, usually available on their website, will provide a list of approved manufacturers and models. Obtaining utility company approval is a mandatory first step.

What is a fifth jaw kit used for in an electric meter base?

A fifth jaw kit is installed in a meter socket to accommodate a meter for a three-phase, four-wire “network” service (208Y/120V). The fifth jaw connects to the neutral conductor and is typically placed in the 9 o’clock position, providing a necessary voltage reference for the meter.

---
