How to Use NEC Table 310.16 for Conductor Ampacity

Correctly using nec table 310.16 is a fundamental skill for every licensed electrician, forming the basis of safe and compliant electrical installations. This essential wire ampacity chart, found in NEC Article 310, provides the allowable ampacities of insulated conductors under specific conditions. Mastering this ampacity table is crucial for accurate conductor ampacity calculation, ensuring that wires are properly sized to handle their load without overheating. The process involves more than just looking up a number; it requires a complete understanding of conductor materials, insulation ratings, terminal temperature limitations, and applying critical ampacity correction factors for ambient temperature and conductor bundling. A firm grasp of this table is the first step in learning how to know what gauge wire to use for any job, from a simple circuit to a full service installation, and is the core of proper wire sizing NEC procedures.

Understanding the Basics of the NEC Ampacity Chart

At its core, NEC Table 310.16 is the primary ampacity chart nec that electricians turn to for determining a conductor’s ampacity. Ampacity is defined in NEC Article 100 as the maximum current, in amperes, that a conductor can carry continuously under the conditions of use without exceeding its temperature rating. Exceeding this value leads to overheating, insulation damage, and a significant fire hazard. This table is the definitive nec wire ampacity chart for the vast majority of common installations.

When you open the NEC to this nec wire size chart, you’ll see several key columns:

• Size (AWG or kcmil): This column lists the conductor size, or cable gauge awg. Note that for smaller gauges like 14 awg wire or 12awg wire, a smaller number means a larger wire, until you get to the aughts (e.g., 1/0, 2/0), and then kcmil. The table does not list values for every small gauge; for a specific application like fixture wire, to find a 16 awg ampacity, you would refer to NEC Table 402.5, even though Table 310.16 also lists ampacities for 16 AWG conductors used in other contexts.
• Temperature Rating Columns (60°C, 75°C, 90°C): These columns contain the ampacity values based on the conductor’s insulation rating. For example, the THHN wire ampacity is found in the 90°C column.
• Copper & Aluminum Columns: The table is split to provide distinct values for copper and aluminum conductors, reflecting the difference in copper vs aluminum ampacity.

This electrical wire size table serves as the starting point for almost every wire size computation. It’s more than a simple wire amp chart; it’s a tool that, when used with other NEC rules, ensures a safe installation.

A Step-by-Step Guide to Conductor Ampacity Calculation

Properly performing a conductor ampacity calculation involves a sequence of critical steps. It’s a process of starting with a baseline value from the table and adjusting it for the real-world conditions of the installation. A mistake at any step can lead to an incorrect and unsafe wire size.

1. Determine Conductor Material and Load: Are you using copper or aluminum? What is the calculated load in amps? For example, the load could be a simple appliance where you can calculate amps from the dryer wattage, or a more complex feeder calculation. Understanding the specific properties of different materials, such as the difference between standard aluminum and copper-clad aluminum conductors, is also essential.
2. Identify Insulation Temperature Rating: Check the conductor’s insulation type (e.g., THHN, THWN-2, XHHW-2). This determines which temperature column (60°C, 75°C, or 90°C conductor rating) to use for your initial ampacity value. The high 8 thhn ampacity comes from its 90°C rating.
3. Comply with Terminal Temperature Limitations (NEC 110.14(C)): This is one of the most critical and often misunderstood steps in wire sizing NEC. NEC 110.14(C) states that the temperature rating associated with the ampacity of a conductor shall not exceed the lowest temperature rating of any connected termination, conductor, or device. For circuits rated 100 amps or less, or those using conductors in the 14 AWG through 1 AWG size range, the ampacity must be based on the 60°C column unless the equipment is marked for a higher temperature rating. For circuits rated over 100 amps, the 75°C column can generally be used. This means even if you use a 90°C wire, you may have to size it based on the 60°C or 75°C ampacity column.
4. Select a Potential Conductor Size: Find your load amperage in the appropriate temperature column (as limited by Step 3) and select the corresponding conductor size.
5. Apply Ampacity Correction Factors: This is the final and most crucial step, involving ampacity derating. You must adjust the conductor’s ampacity from the table for ambient temperature and the number of conductors in a raceway. The final, adjusted ampacity must be sufficient for the load and protected by the appropriate overcurrent device.

Critical Ampacity Correction and Adjustment Factors

The values in the nec ampacity table are based on specific conditions: an ambient temperature of 30°C (86°F) and no more than three current-carrying conductors in a raceway or cable. When your installation deviates, you must apply ampacity correction factors.

Ambient Temperature Correction

If your conductors will be installed in an environment hotter than 86°F (e.g., an attic, on a rooftop), you must apply an ambient temperature correction. NEC Table 310.15(B)(1) provides the correction factors. You multiply the conductor’s ampacity from Table 310.16 by this factor. For instance, a wire run through a 120°F space will have its ampacity significantly reduced.

Raceway Conductor Adjustment (Conductor Bundling Derating)

When you have more than three current-carrying conductors in a single raceway or cable, their mutual heat buildup reduces their ability to dissipate heat. This requires a raceway conductor adjustment, also known as conductor bundling derating. NEC Table 310.15(C)(1) provides these adjustment factors. For example, bundling 4-6 conductors requires you to reduce their ampacity to 80% of the table value. This is a critical factor when considering questions like how many computer on one breaker, as multiple shared neutral circuits can result in more than three current-carrying conductors requiring derating.

These complex adjustments for specialized loads, such as those found in EV charging stations or motor-driven equipment, highlight the need for ongoing professional education. For example, properly calculating loads for an EVSE requires specific knowledge beyond a simple table lookup, just as the NEC has specific rules that can simplify motor conductor sizing. Feeling confident in every calculation is paramount. Master the NEC code book and perform accurate calculations every time.

Practical Examples and Common Wire Size Lookups

Let’s apply these principles to common scenarios. This is how to know what gauge wire to use in the field.

What Size Wire for 50 Amps? (50 Amp Wire Size)

A common question is, “what size wire for 50 amps?” or “what size wire for 50 amp breaker?”. For a 50 amp wire size using copper, the answer depends heavily on terminal temperature ratings. If terminals are rated for 75°C, a #8 AWG copper conductor is rated for 50A and is a common choice. However, it’s critical to verify this; if terminals were rated at only 60°C, that same #8 AWG wire is only rated for 40A and would be undersized. The final choice for a 50 amp wire always depends on correction factors and verified terminal ratings.

Sizing for a 100 Amp Sub Panel (100 Amp Wire Size)

For a 100 amp wire size, such as determining the 100 amp sub panel wire size, a common choice is aluminum SER cable. When asked what size wire for 100 amp sub panel, you would look at the 75°C column. For aluminum, a 2/0 aluminum wire is rated for 135A, but a 1/0 al wire is only rated for 120A. A popular and code-compliant choice for a wire size for 100 amp sub panel is #2 AWG copper (115A) or #1/0 AWG aluminum (120A). For a mobile home feeder wire 100 amp service, these sizes are also typical starting points before any derating.

Sizing for Other Common Loads and Services

The same process applies to other loads. For a 30 amp wire size (e.g., a dryer), #10 AWG copper is standard. For a 40 amp wire size, #8 AWG copper is used. For a 60 amp wire size, #6 AWG copper or #4 AWG aluminum is the starting point. When determining the size of wire for 60 amp or the correct 60 amp breaker wire size, always apply the principles of terminal ratings and derating. For larger services, like finding the 200 amp service wire size, a common choice is 4/0 aluminum wire (also written as 4 0 aluminum wire or 4-0 aluminum electrical wire), as its 4/0 aluminum wire ampacity of 180A is permitted to be protected by a 200A breaker per NEC 240.4(B) for services. The 400 amp wire size requires even larger conductors, often paralleled sets.

A Note on Grounding and Circuit Loading

Remember that this ampacity of cable table does not size the ground wire. For that, you must consult the ground wire size chart in NEC Table 250.122, which is the official nec ground wire size chart or equipment grounding conductor chart. Also, this table doesn’t directly answer questions like “how many outlets on a 20 amp circuit?” or “how many receptacles on a 20 amp circuit?”. While a 12awg wire is used for a 20A circuit, the number of receptacles is governed by load calculations in Article 220, not wire ampacity alone. The same applies to “how many outlets on a 15 amp circuit,” which uses 14 awg wire and has a maximum of 1440 watts based on the common question “how many watts on a 15 amp circuit” (120V * 15A * 80%).

Key Takeaways for Using NEC Table 310.16

Navigating the various NEC ampacity charts can be complex. While a size electrical wire calculator can be a helpful tool for quick estimates, it cannot replace professional knowledge. Here are the most important takeaways:

• Always start with Table 310.16: It is the foundation for determining the allowable ampacities of insulated conductors.
• Respect Terminal Ratings: NEC 110.14(C) is not optional. Your conductor choice is limited by the lowest temperature rating of any termination or device in the circuit.
• Derate, Derate, Derate: Always apply ampacity derating for ambient temperature and conductor bundling. This is the most common source of calculation errors.
• Use the Right Column: The distinction between copper vs aluminum ampacity is significant. Double-check that you are using the correct material column.
• Voltage Drop is a Separate Calculation: This table does not account for voltage drop over long distances. A wire length calculator and the formulas in NEC Chapter 9 are needed for that separate, but equally important, calculation.
• Understand the Complete Picture: Proper overcurrent protection sizing, grounding conductor sizing, and load calculations are all part of a compliant installation. Knowing a specific value like the 8 gauge wire amp rating (or amp capacity of 8 gauge wire) is just one piece of the puzzle.

Frequently Asked Questions (FAQ)

How do I determine the correct 100 amp wire size using nec table 310.16?

To find the 100 amp wire size, you first determine your conductor material (copper or aluminum) and check terminal temperature ratings. Although many terminals are rated 75°C, NEC 110.14(C)(1) requires that for circuits 100A or less, the ampacity is determined from the 60°C column unless the equipment is marked for a higher rating. Assuming the terminals *are* marked for 75°C, you would use the 75°C column of nec table 310.16 to find that #3 copper (100A) or #1 aluminum (100A) are the minimum sizes before any derating is applied. Answering “what size wire for 100 amp service” requires carefully verifying these ratings.

What’s the difference between the 75°C and 90°C conductor rating columns?

The columns correspond to the maximum temperature the conductor’s insulation can safely handle. While a wire may have a 90°C conductor rating (like THHN), you often cannot use its higher ampacity value. Per NEC 110.14(C), the terminal temperature limitations of breakers and equipment (often 75°C) restrict you to using the ampacity from the 75°C column. The 90°C value is primarily used as the starting point for derating calculations.

Does the nec wire ampacity chart tell me how many outlets on a 20 amp circuit?

No. The nec wire ampacity chart tells you the safe current-carrying capacity of the wire itself (e.g., 12awg wire for a 20A circuit). The question “how many 20 amp receptacle on a circuit” is answered by NEC Article 220, which covers load calculations. For general-purpose branch circuits in a dwelling, the NEC does not specify a maximum number of receptacles. However, for non-dwelling occupancies, a load calculation of 180 volt-amperes (1.5A at 120V) per receptacle yoke is used per NEC 220.14(I), which would equate to 10 receptacles on a 15A circuit and 13 on a 20A circuit. This calculation method is often used as a guideline but is not a strict limit for residential installations.

What is the 8 gauge wire amp rating according to the ampacity chart nec?

The 8 gauge wire amp rating (also phrased as 8 awg wire amps or amp rating for 8 gauge wire) depends on the material and temperature column. According to the ampacity chart nec (Table 310.16), the 8awg wire ampacity for copper is 40A at 60°C, 50A at 75°C, and 55A at 90°C. The #8 thhn ampacity would start at 55A before any adjustments. For aluminum, the amp capacity of 8 gauge wire is 30A at 60°C, 40A at 75°C, and 45A at 90°C.

Primary Sources

This article is written for informational purposes and is not a substitute for the official National Electrical Code®. For the most accurate and up-to-date requirements, always refer to the latest edition of the NEC, published by the National Fire Protection Association (NFPA).

• NFPA 70, National Electrical Code®
